Brand : Jinwoseal
Warranty :12 months
Fitment Type : Direct Replacement
Weight: 30g
Applicable model : Caterpillar
Jinwoseal is a company that focuses on providing high-quality sealing solutions.This product is a sealing device for water pumps, designed to prevent liquid leakage while allowing the pump shaft to rotate freely. The working principle of the water pump shaft seal mechanical seal is based on the relative movement between the stationary ring and the dynamic ring.
When the pump shaft rotates, the dynamic ring rotates with the shaft, forming a sealing interface with the stationary ring to prevent liquid leakage. The spring provides the necessary contact pressure to ensure the sealing effect. The material selection of the water pump shaft seal mechanical seal is crucial, and we provide the following material options.
| Component Name | Material Options |
| Retainer | SUS304 SUS316 SUS430 1Cr18Ni9, 0Cr18Ni9 |
| Bellows Seat | |
| Spring Seats | |
| Stationary Ring | Hot Pressed Resin Carbon |
| Sintered Impregnated Carbon | |
| Hard Carbon | |
| Silicon Carbide Composite | |
| Rotary Ring | Alumina Ceramics |
| Silicon Carbide | |
| Silicon Carbide Composite | |
| Spring | SUS304, SUS316, 1Cr18Ni9, 0cr18Ni9 |
| Carbon Steel Wire | |
| Cup Ring | NBR HNBR |
| Bellows |
Complete pre-sales service: answer any questions from customers, introduce company products, commodity quotations, provide sample services, accept customized products
Responsible in-sales service: confirm production plan, take photos to inspect products, strict packaging, reliable transportation, document records
Reliable after-sales service: solve any problems of customers regarding orders, collect
